101: Onnx Model Rewriting

This example shows how to rewrite a graph using a pattern.

A model

from typing import List, Optional
import onnx.helper as oh
from onnx import NodeProto, TensorProto
from onnx_array_api.plotting.text_plot import onnx_simple_text_plot
from onnx_array_api.plotting.graphviz_helper import plot_dot
from experimental_experiment.xbuilder.graph_builder import (
    GraphBuilder,
    OptimizationOptions,
)
from experimental_experiment.xoptim import EasyPatternOptimization


proto = oh.make_model(
    oh.make_graph(
        [
            oh.make_node("Sigmoid", ["Y"], ["sy"]),
            oh.make_node("Mul", ["Y", "sy"], ["ysy"]),
            oh.make_node("Mul", ["X", "ysy"], ["final"]),
        ],
        "nd",
        [
            oh.make_tensor_value_info("X", TensorProto.FLOAT, [1, "b", "c"]),
            oh.make_tensor_value_info("Y", TensorProto.FLOAT, ["a", "b", "c"]),
        ],
        [oh.make_tensor_value_info("final", TensorProto.FLOAT, ["a", "b", "c"])],
    ),
    opset_imports=[oh.make_opsetid("", 18)],
    ir_version=9,
)


print(onnx_simple_text_plot(proto))

opset: domain='' version=18
input: name='X' type=dtype('float32') shape=[1, 'b', 'c']
input: name='Y' type=dtype('float32') shape=['a', 'b', 'c']
Sigmoid(Y) -> sy
  Mul(Y, sy) -> ysy
    Mul(X, ysy) -> final
output: name='final' type=dtype('float32') shape=['a', 'b', 'c']

And visually.

plot_dot(proto)

<Axes: >

The pattern

class MulMulSigmoidPattern(EasyPatternOptimization):
    def match_pattern(self, g: GraphBuilder, X, Y):
        return g.op.Mul(X, g.op.Mul(Y, g.op.Sigmoid(Y)))

    def apply_pattern(self, g: GraphBuilder, X, Y):
        return g.anyop.MulMulSigmoid(X, Y, domain="onnx_extended.ortops.optim.cuda")

Optimization

gr = GraphBuilder(
    proto,
    infer_shapes=True,
    optimization_options=OptimizationOptions(
        patterns=[MulMulSigmoidPattern(verbose=1)],
        verbose=1,  # a higher value increases the verbosity when optimizations for patterns
    ),
)

new_proto = gr.to_onnx()
print(onnx_simple_text_plot(new_proto))

[GraphBuilder.optimize] start with 3 nodes
[GraphBuilder.optimize] options=OptimizationOptions(remove_unused=True, remove_identity=True,
    constant_folding=False, constant_size=1024, constant_fusing=True, verbose=1,
    max_iter=-1, recursive=False, processor=CPU, order=None,
    patterns=['MulMulSigmoidPattern'])
[GraphBuilderPatternOptimization.optimize] start with 3 nodes and 1 patterns, priorities=[0]
[GraphBuilderPatternOptimization.optimize] use pattern   1/1 - P0 - MulMulSigmoidPattern()
[GraphBuilderPatternOptimization.optimize] iteration 0: 3 nodes, priority=0
[GraphBuilderPatternOptimization.optimize] applies 1 matches, [0]=MatchResult: MulMulSigmoidPattern replaces ['Sigmoid', 'Mul', 'Mul'] - time=0.001 | max_time=MulMulSigmoidPattern:0.001
[GraphBuilderPatternOptimization.optimize] iteration 1: 1 nodes, priority=0
[GraphBuilderPatternOptimization.optimize] done after 2 iterations with 1 nodes in 0.001
[GraphBuilder.optimize] done with 1 nodes in 0.002
    STAT apply_MulMulSigmoidPattern +1 -3 #it=1 maxmatch=0 i=1 - time=0.0003088119992753491
    STAT build_for_pattern +0 -0 #it=2 maxmatch=0 i=0 - time=1.562999932502862e-05
    STAT check_A +0 -0 #it=0 maxmatch=0 i=0 - time=1.885599886009004e-05
    STAT check_B +0 -0 #it=0 maxmatch=0 i=0 - time=9.018000127980486e-06
    STAT check_C +0 -0 #it=0 maxmatch=0 i=0 - time=8.424998668488115e-06
    STAT check_F +0 -0 #it=0 maxmatch=0 i=0 - time=5.678999514202587e-06
    STAT check_G +0 -0 #it=0 maxmatch=0 i=0 - time=3.4559998312033713e-06
    STAT check_pattern_00 +0 -0 #it=1 maxmatch=0 i=0 - time=1.4908000594004989e-05
    STAT check_pattern_A0 +0 -0 #it=1 maxmatch=0 i=0 - time=6.415000825654715e-06
    STAT check_pattern_B0 +0 -0 #it=2 maxmatch=0 i=0 - time=9.16399949346669e-06
    STAT match_MulMulSigmoidPattern +0 -0 #it=2 maxmatch=1 i=1 - time=0.0009488329978921684
    STAT pattern_optimization +0 -2 #it=0 maxmatch=0 i=0 - time=0.0016338309997081524
    STAT remove_identity_nodes +0 -0 #it=2 maxmatch=0 i=0 - time=4.811699909623712e-05
    STAT remove_unused +0 -0 #it=0 maxmatch=0 i=0 - time=3.932700019504409e-05
--MODEL: 1 nodes, 2 inputs, 1 outputs, 0 initializers--
     INPUT:   2 x 1t
    OUTPUT:   1 x 1t
      NODE:   1 x onnx_extended.ortops.optim.cuda.MulMulSigmoid
--MODEL: 1 nodes, 2 inputs, 1 outputs, 0 initializers--DETAILED--
     INPUT:   1 x 1t[1xbxc]
     INPUT:   1 x 1t[axbxc]
    OUTPUT:   1 x 1t[axbxc]
      NODE:   1 x onnx_extended.ortops.optim.cuda.MulMulSigmoid -SIG- 1t[1xbxc], 1t[axbxc]
opset: domain='' version=18
opset: domain='onnx_extended.ortops.optim.cuda' version=1
input: name='X' type=dtype('float32') shape=[1, 'b', 'c']
input: name='Y' type=dtype('float32') shape=['a', 'b', 'c']
MulMulSigmoid[onnx_extended.ortops.optim.cuda](X, Y) -> final
output: name='final' type=dtype('float32') shape=['a', 'b', 'c']

And visually.

plot_dot(new_proto)

<Axes: >

Filtering

Let’s assume now we want to apply the pattern only when the shapes are identical.

class MulMulSigmoidPattern2(EasyPatternOptimization):
    def match_pattern(self, g: GraphBuilder, X, Y):
        return g.op.Mul(X, g.op.Mul(Y, g.op.Sigmoid(Y)))

    def apply_pattern(self, g: GraphBuilder, X, Y):
        return g.anyop.MulMulSigmoid(X, Y, domain="onnx_extended.ortops.optim.cuda")

    def validate_mapping(
        self,
        g: GraphBuilder,
        deleted_nodes: List[NodeProto],
        pattern_nodes: Optional[List[NodeProto]] = None,
    ) -> bool:
        for node in deleted_nodes:
            if (
                node.op_type == "Mul"
                and g.has_shape(node.input[0])
                and g.has_shape(node.input[1])
            ):
                sh1 = g.get_shape(node.input[0])
                sh2 = g.get_shape(node.input[1])
                if sh1 != sh2:
                    if self.verbose > 0:
                        print(
                            f"[MulMulSigmoidPattern2.validate_mapping] "
                            f"match not valid because shapes are different"
                            f"{node.input[0]}:{sh1} != {node.input[1]}:{sh2}"
                        )
                    return False
        return True


gr = GraphBuilder(
    proto,
    infer_shapes=True,
    optimization_options=OptimizationOptions(
        patterns=[MulMulSigmoidPattern2(verbose=1)],
        verbose=0,
    ),
)

new_proto = gr.to_onnx()
print(onnx_simple_text_plot(new_proto))

[MulMulSigmoidPattern2.validate_mapping] match not valid because shapes are differentX:(1, 'b', 'c') != ysy:('a', 'b', 'c')
opset: domain='' version=18
input: name='X' type=dtype('float32') shape=[1, 'b', 'c']
input: name='Y' type=dtype('float32') shape=['a', 'b', 'c']
Sigmoid(Y) -> sy
  Mul(Y, sy) -> ysy
    Mul(X, ysy) -> final
output: name='final' type=dtype('float32') shape=['a', 'b', 'c']
