Export a model with a control flow (If)¶

Control flow cannot be exported with a change. The code of the model can be changed or patched to introduce function torch.cond().

A model with a test¶

import torch
from onnx_diagnostic import doc
from onnx_diagnostic.torch_export_patches import torch_export_rewrite

We define a model with a control flow (-> graph break)

class ForwardWithControlFlowTest(torch.nn.Module):
    def forward(self, x):
        if x.sum():
            return x * 2
        else:
            return -x


class ModelWithControlFlow(torch.nn.Module):
    def __init__(self):
        super().__init__()
        self.mlp = torch.nn.Sequential(
            torch.nn.Linear(3, 2),
            torch.nn.Linear(2, 1),
            ForwardWithControlFlowTest(),
        )

    def forward(self, x):
        out = self.mlp(x)
        return out


model = ModelWithControlFlow()

Let’s check it runs.

x = torch.randn(1, 3)
model(x)

tensor([[0.8866]], grad_fn=<MulBackward0>)

As expected, it does not export.

try:
    torch.export.export(model, (x,))
    raise AssertionError("This export should failed unless pytorch now supports this model.")
except Exception as e:
    print(e)

def forward(self, arg0_1: "f32[2, 3]", arg1_1: "f32[2]", arg2_1: "f32[1, 2]", arg3_1: "f32[1]", arg4_1: "f32[1, 3]"):
     # File: ~/vv/this312/lib/python3.12/site-packages/torch/nn/modules/linear.py:125 in forward, code: return F.linear(input, self.weight, self.bias)
    linear: "f32[1, 2]" = torch.ops.aten.linear.default(arg4_1, arg0_1, arg1_1);  arg4_1 = arg0_1 = arg1_1 = None
    linear_1: "f32[1, 1]" = torch.ops.aten.linear.default(linear, arg2_1, arg3_1);  linear = arg2_1 = arg3_1 = None

     # File: ~/github/onnx-diagnostic/_doc/recipes/plot_export_cond.py:26 in forward, code: if x.sum():
    sum_1: "f32[]" = torch.ops.aten.sum.default(linear_1);  linear_1 = None
    ne: "b8[]" = torch.ops.aten.ne.Scalar(sum_1, 0);  sum_1 = None
    item: "Sym(Eq(u0, 1))" = torch.ops.aten.item.default(ne);  ne = item = None




def forward(self, arg0_1: "f32[2, 3]", arg1_1: "f32[2]", arg2_1: "f32[1, 2]", arg3_1: "f32[1]", arg4_1: "f32[1, 3]"):
     # File: ~/vv/this312/lib/python3.12/site-packages/torch/nn/modules/linear.py:125 in forward, code: return F.linear(input, self.weight, self.bias)
    linear: "f32[1, 2]" = torch.ops.aten.linear.default(arg4_1, arg0_1, arg1_1);  arg4_1 = arg0_1 = arg1_1 = None
    linear_1: "f32[1, 1]" = torch.ops.aten.linear.default(linear, arg2_1, arg3_1);  linear = arg2_1 = arg3_1 = None

     # File: ~/github/onnx-diagnostic/_doc/recipes/plot_export_cond.py:26 in forward, code: if x.sum():
    sum_1: "f32[]" = torch.ops.aten.sum.default(linear_1);  linear_1 = None
    ne: "b8[]" = torch.ops.aten.ne.Scalar(sum_1, 0);  sum_1 = None
    item: "Sym(Eq(u0, 1))" = torch.ops.aten.item.default(ne);  ne = item = None

Could not guard on data-dependent expression Eq(u0, 1) (unhinted: Eq(u0, 1)).  (Size-like symbols: none)

Caused by: (_export/non_strict_utils.py:973 in __torch_function__)
For more information, run with TORCH_LOGS="dynamic"
For extended logs when we create symbols, also add TORCHDYNAMO_EXTENDED_DEBUG_CREATE_SYMBOL="u0"
If you suspect the guard was triggered from C++, add TORCHDYNAMO_EXTENDED_DEBUG_CPP=1
For more debugging help, see https://docs.google.com/document/d/1HSuTTVvYH1pTew89Rtpeu84Ht3nQEFTYhAX3Ypa_xJs/edit?usp=sharing

For C++ stack trace, run with TORCHDYNAMO_EXTENDED_DEBUG_CPP=1

The following call raised this error:
  File "~/github/onnx-diagnostic/_doc/recipes/plot_export_cond.py", line 26, in forward
    if x.sum():


The error above occurred when calling torch.export.export. If you would like to view some more information about this error, and get a list of all other errors that may occur in your export call, you can replace your `export()` call with `draft_export()`.

Suggested Patch¶

Let’s avoid the graph break by replacing the forward.

def new_forward(x):
    def identity2(x):
        return x * 2

    def neg(x):
        return -x

    return torch.cond(x.sum() > 0, identity2, neg, (x,))


print("the list of submodules")
for name, mod in model.named_modules():
    print(name, type(mod))
    if isinstance(mod, ForwardWithControlFlowTest):
        mod.forward = new_forward

the list of submodules
 <class '__main__.ModelWithControlFlow'>
mlp <class 'torch.nn.modules.container.Sequential'>
mlp.0 <class 'torch.nn.modules.linear.Linear'>
mlp.1 <class 'torch.nn.modules.linear.Linear'>
mlp.2 <class '__main__.ForwardWithControlFlowTest'>

Let’s see what the fx graph looks like.

ep = torch.export.export(model, (x,))
print(ep.graph)

graph():
    %p_mlp_0_weight : [num_users=1] = placeholder[target=p_mlp_0_weight]
    %p_mlp_0_bias : [num_users=1] = placeholder[target=p_mlp_0_bias]
    %p_mlp_1_weight : [num_users=1] = placeholder[target=p_mlp_1_weight]
    %p_mlp_1_bias : [num_users=1] = placeholder[target=p_mlp_1_bias]
    %x : [num_users=1] = placeholder[target=x]
    %linear : [num_users=1] = call_function[target=torch.ops.aten.linear.default](args = (%x, %p_mlp_0_weight, %p_mlp_0_bias), kwargs = {})
    %linear_1 : [num_users=2] = call_function[target=torch.ops.aten.linear.default](args = (%linear, %p_mlp_1_weight, %p_mlp_1_bias), kwargs = {})
    %sum_1 : [num_users=1] = call_function[target=torch.ops.aten.sum.default](args = (%linear_1,), kwargs = {})
    %gt : [num_users=1] = call_function[target=torch.ops.aten.gt.Scalar](args = (%sum_1, 0), kwargs = {})
    %true_graph_0 : [num_users=1] = get_attr[target=true_graph_0]
    %false_graph_0 : [num_users=1] = get_attr[target=false_graph_0]
    %cond : [num_users=1] = call_function[target=torch.ops.higher_order.cond](args = (%gt, %true_graph_0, %false_graph_0, (%linear_1,)), kwargs = {})
    %getitem : [num_users=1] = call_function[target=operator.getitem](args = (%cond, 0), kwargs = {})
    return (getitem,)

Automated Rewrite of the Control Flow¶

Functions torch_export_rewrite or torch_export_patches can automatically rewrite a method of a class or a function, the method to rewrite is specified parameter rewrite. It is experimental. The function contains options to rewrite one test but not another one already supported by the exporter. It may give a first version of the rewritten code if only a manual rewriting can make the model exportable.

with torch_export_rewrite(rewrite=[ForwardWithControlFlowTest.forward], verbose=2) as f:
    ep = torch.export.export(model, (x,))

[torch_export_rewrite] rewrites method ForwardWithControlFlowTest.forward
[transform_method] -- source -- <function ForwardWithControlFlowTest.forward at 0x7f25fe5374c0>

    def forward(self, x):
        if x.sum():
            return x * 2
        else:
            return -x


[transform_method] --
[transform_method] -- new code --

def forward(self, x):

    def branch_cond_then_1(x):
        return x * 2

    def branch_cond_else_1(x):
        return -x
    return torch.cond(x.sum(), branch_cond_then_1, branch_cond_else_1, [x])

[transform_method] --
[torch_export_rewrite] restored method ForwardWithControlFlowTest.forward

This gives:

print(ep.graph)

graph():
    %p_mlp_0_weight : [num_users=1] = placeholder[target=p_mlp_0_weight]
    %p_mlp_0_bias : [num_users=1] = placeholder[target=p_mlp_0_bias]
    %p_mlp_1_weight : [num_users=1] = placeholder[target=p_mlp_1_weight]
    %p_mlp_1_bias : [num_users=1] = placeholder[target=p_mlp_1_bias]
    %x : [num_users=1] = placeholder[target=x]
    %linear : [num_users=1] = call_function[target=torch.ops.aten.linear.default](args = (%x, %p_mlp_0_weight, %p_mlp_0_bias), kwargs = {})
    %linear_1 : [num_users=2] = call_function[target=torch.ops.aten.linear.default](args = (%linear, %p_mlp_1_weight, %p_mlp_1_bias), kwargs = {})
    %sum_1 : [num_users=1] = call_function[target=torch.ops.aten.sum.default](args = (%linear_1,), kwargs = {})
    %gt : [num_users=1] = call_function[target=torch.ops.aten.gt.Scalar](args = (%sum_1, 0), kwargs = {})
    %true_graph_0 : [num_users=1] = get_attr[target=true_graph_0]
    %false_graph_0 : [num_users=1] = get_attr[target=false_graph_0]
    %cond : [num_users=1] = call_function[target=torch.ops.higher_order.cond](args = (%gt, %true_graph_0, %false_graph_0, (%linear_1,)), kwargs = {})
    %getitem : [num_users=1] = call_function[target=operator.getitem](args = (%cond, 0), kwargs = {})
    return (getitem,)

doc.plot_legend("If -> torch.cond", "torch.export.export", "yellowgreen")

Total running time of the script: (0 minutes 9.404 seconds)
