Computed Shapes: Add + Concat + Reshape

This example shows how BasicShapeBuilder tracks symbolic dimension expressions through a sequence of Add, Concat, and Reshape nodes, and compares the result with the standard onnx.shape_inference.infer_shapes().

The key difference is that onnx.shape_inference.infer_shapes can only propagate shapes when dimensions are statically known integers. When the model contains dynamic (symbolic) dimensions it typically assigns None (unknown) to most intermediate results. BasicShapeBuilder instead keeps the dimensions as symbolic arithmetic expressions so that output shapes are expressed in terms of the input dimension names.

See ShapeBuilder for a detailed description of how BasicShapeBuilder works and a comparison table with onnx.shape_inference.infer_shapes().

import numpy as np
import onnx
import onnx.helper as oh
import onnx.numpy_helper as onh
from yobx.reference import ExtendedReferenceEvaluator
from yobx.xshape import BasicShapeBuilder

TFLOAT = onnx.TensorProto.FLOAT

Build a small model

The graph performs the following steps:

1. Add(X, Y) — element-wise addition of two tensors with shape (batch, seq, d_model).

2. Concat(added, X, axis=2) — concatenate the result with the original X along the last axis, giving shape (batch, seq, 2*d_model).

3. Reshape(concat_out, shape) — flatten the last two dimensions using a fixed shape constant [0, 0, -1], which collapses (batch, seq, 2*d_model) back to (batch, seq, 2*d_model).

model = oh.make_model(
    oh.make_graph(
        [
            oh.make_node("Add", ["X", "Y"], ["added"]),
            oh.make_node("Concat", ["added", "X"], ["concat_out"], axis=2),
            oh.make_node("Reshape", ["concat_out", "reshape_shape"], ["Z"]),
        ],
        "add_concat_reshape",
        [
            oh.make_tensor_value_info("X", TFLOAT, ["batch", "seq", "d_model"]),
            oh.make_tensor_value_info("Y", TFLOAT, ["batch", "seq", "d_model"]),
        ],
        [oh.make_tensor_value_info("Z", TFLOAT, [None, None, None])],
        [
            onh.from_array(np.array([0, 0, -1], dtype=np.int64), name="reshape_shape"),
        ],
    ),
    opset_imports=[oh.make_opsetid("", 18)],
    ir_version=10,
)

Shape inference with ONNX

onnx.shape_inference.infer_shapes propagates shapes through the model. For dynamic dimensions the inferred shapes for intermediate results are often unknown (None).

inferred = onnx.shape_inference.infer_shapes(model)

print("=== onnx.shape_inference.infer_shapes ===")
for vi in (
    list(inferred.graph.input) + list(inferred.graph.value_info) + list(inferred.graph.output)
):
    t = vi.type.tensor_type
    if t.HasField("shape"):
        shape = tuple(
            d.dim_param if d.dim_param else (d.dim_value if d.dim_value else None)
            for d in t.shape.dim
        )
    else:
        shape = "unknown"
    print(f"  {vi.name:15s}  shape={shape}")

=== onnx.shape_inference.infer_shapes ===
  X                shape=('batch', 'seq', 'd_model')
  Y                shape=('batch', 'seq', 'd_model')
  added            shape=('batch', 'seq', 'd_model')
  concat_out       shape=('batch', 'seq', 'unk__0')
  Z                shape=('batch', 'seq', 'unk__1')

Shape inference with BasicShapeBuilder

BasicShapeBuilder keeps the shapes as symbolic expressions. Because reshape_shape is a constant [0, 0, -1], the builder can evaluate the Reshape and express the output shape as a function of the input dimensions.

builder = BasicShapeBuilder()
builder.run_model(model)

print("\n=== BasicShapeBuilder ===")
for name in ["X", "Y", "added", "concat_out", "Z"]:
    print(f"  {name:15s}  shape={builder.get_shape(name)}")

=== BasicShapeBuilder ===
  X                shape=('batch', 'seq', 'd_model')
  Y                shape=('batch', 'seq', 'd_model')
  added            shape=('batch', 'seq', 'd_model')
  concat_out       shape=('batch', 'seq', '2*d_model')
  Z                shape=('batch', 'seq', '2*d_model')

Evaluate symbolic shapes with concrete values

Once the concrete values of the dynamic dimensions are known, evaluate_shape resolves each symbolic expression to its actual integer value.

context = dict(batch=2, seq=5, d_model=8)
for name in ["X", "Y", "added", "concat_out", "Z"]:
    concrete = builder.evaluate_shape(name, context)
    print(f"  {name:15s}  concrete shape={concrete}")

X                concrete shape=(2, 5, 8)
Y                concrete shape=(2, 5, 8)
added            concrete shape=(2, 5, 8)
concat_out       concrete shape=(2, 5, 16)
Z                concrete shape=(2, 5, 16)

Verify with real data

Finally, run the model with concrete numpy arrays and confirm that the shapes predicted by BasicShapeBuilder match the actual output shapes.

feeds = {
    "X": np.random.rand(2, 5, 8).astype(np.float32),
    "Y": np.random.rand(2, 5, 8).astype(np.float32),
}

session = ExtendedReferenceEvaluator(model)
outputs = session.run(None, feeds)
result = builder.compare_with_true_inputs(feeds, outputs)
print("\n=== shape comparison (expr, expected, computed) ===")
for name, dims in result.items():
    print(f"  {name}: {dims}")

=== shape comparison (expr, expected, computed) ===
  Z: (('batch', 2, 2), ('seq', 5, 5), ('2*d_model', 16, 16))
