Export with DynamicCache and guessed dynamic shapes¶
Every LLMs implemented in transformers use cache.
One of the most used is transformers.cache_utils.DynamicCache.
The cache size is dynamic to cope with the growing context.
The example shows a tool which determines the dynamic shapes
for torch.export.export() based on a set of valid inputs.
DynamicCache¶
torch.export.export() serializes caches and any custom class
if these serialization functions are provided with is the case for
transformers.cache_utils.DynamicCache and transformers>=4.50.
The dynamic shapes must be provided following the serialized form.
import pprint
import torch
from onnx_diagnostic import doc
from onnx_diagnostic.helpers import string_type
from onnx_diagnostic.helpers.cache_helper import (
flatten_unflatten_for_dynamic_shapes,
make_dynamic_cache,
CacheKeyValue,
)
from onnx_diagnostic.export import ModelInputs
from onnx_diagnostic.torch_export_patches import torch_export_patches
class Model(torch.nn.Module):
def forward(self, cache, z):
cache = CacheKeyValue(cache)
return (
z
+ cache.key_cache[0]
+ cache.key_cache[1]
+ cache.value_cache[0]
+ cache.value_cache[1]
)
model = Model()
n_layers = 2
bsize, nheads, slen, dim = 2, 4, 3, 7
cache = make_dynamic_cache(
[
(torch.randn(bsize, nheads, slen, dim), torch.randn(bsize, nheads, slen, dim))
for i in range(n_layers)
]
)
z = torch.randn((1, 1, 1, 7))
model(cache, z) # to check it works.
tensor([[[[ 1.2065e+00, 4.2592e+00, -5.0596e-01, 3.7851e+00, 1.6995e+00,
-1.2802e+00, -1.5096e+00],
[-8.6155e-01, -1.9605e+00, 1.9830e+00, 2.5508e+00, 2.0251e+00,
2.2704e+00, 4.0910e-02],
[ 1.5919e-01, -9.7137e-01, 9.0396e-01, 3.2832e+00, 3.9668e+00,
1.5895e+00, -4.3324e+00]],
[[ 3.3668e+00, -1.4471e+00, -2.2153e-01, 1.8183e+00, 4.5027e-01,
1.2779e+00, 3.7411e-01],
[-1.9475e+00, -4.5119e-01, 1.2478e+00, 2.5660e+00, 2.7818e+00,
-1.8669e+00, 4.1276e-01],
[ 1.8003e+00, 5.3775e-01, 1.5675e+00, -4.7837e-01, 5.3404e-01,
4.6559e-01, 8.6670e-01]],
[[ 2.4356e+00, 4.0516e-01, 1.2190e+00, 2.9211e+00, 4.7782e-01,
-1.4041e+00, -8.1459e-01],
[ 2.0599e+00, -1.1782e+00, 1.6312e+00, 1.5066e+00, 1.9275e+00,
3.4996e+00, 7.6782e-01],
[ 3.4057e+00, 3.9317e-01, 2.6442e+00, -3.0205e-01, 1.1599e+00,
2.8338e+00, -1.2043e+00]],
[[-2.3608e+00, 3.0060e+00, -1.7603e-01, 1.0714e+00, -8.0234e-01,
-1.2117e-01, 6.9854e-01],
[-2.1983e-01, 1.6605e+00, 2.8058e+00, -1.4066e-02, -6.4126e-01,
-2.0381e+00, 1.0112e+00],
[ 2.1301e-01, -1.8910e+00, 1.2207e+00, 1.6962e+00, 3.8539e+00,
2.5187e+00, 4.4274e-01]]],
[[[-1.0759e+00, 8.8161e-01, -1.2863e+00, -6.8479e-01, 3.4326e+00,
-9.7247e-01, 1.9581e+00],
[-4.9716e+00, -7.2541e-01, 2.1058e+00, -1.4056e+00, -1.7904e+00,
3.2410e+00, 1.1777e-01],
[-1.3734e+00, -1.0456e+00, 4.2197e-01, 2.0193e+00, 7.3696e-01,
-1.0122e+00, 1.0726e+00]],
[[-7.7517e-01, -2.5451e+00, 3.4221e+00, 1.3313e+00, 2.8932e+00,
-8.5541e-01, 2.1524e+00],
[-1.6473e+00, -2.5183e+00, -5.5573e-01, -4.3489e-03, 1.2963e+00,
1.5930e+00, -1.7775e+00],
[-2.1222e+00, 1.3105e+00, 1.7864e+00, -1.0606e+00, 2.2835e+00,
2.3810e+00, -4.6853e-01]],
[[ 5.2642e-01, 3.6147e-01, -1.1354e+00, 2.2141e+00, 2.3492e+00,
3.7347e-01, -9.1122e-01],
[-9.5342e-01, 6.7934e-01, 1.3236e+00, 2.9452e+00, 3.2378e+00,
3.8519e+00, 2.2207e+00],
[ 1.1340e+00, -5.2686e-01, 3.0743e+00, 5.1192e-01, 2.7586e+00,
-2.3406e-01, -4.7315e+00]],
[[-1.7984e-01, -5.5359e+00, 4.4568e+00, -2.4558e+00, 2.8290e+00,
-1.3754e+00, -6.1635e-01],
[ 4.3120e-01, -9.4078e-01, 4.4439e+00, 3.2635e+00, 1.1788e+00,
2.2735e+00, 5.2567e-01],
[ 1.7179e+00, 7.3110e-01, 3.8122e+00, 8.0327e-01, 6.0578e+00,
-9.5705e-01, 2.2877e-01]]]])
The cache looks like this:
print(string_type(cache, with_shape=True))
DynamicCache(key_cache=#2[T1s2x4x3x7,T1s2x4x3x7], value_cache=#2[T1s2x4x3x7,T1s2x4x3x7])
cache2 = make_dynamic_cache(
[
(
torch.randn(bsize + 1, nheads, slen + 1, dim + 1),
torch.randn(bsize + 1, nheads, slen + 1, dim + 1),
)
for i in range(n_layers)
]
)
inputs = [
(cache, z),
(cache2, torch.randn((1, 1, 1, 8))),
]
And the second set of inputs looks like:
print(string_type(inputs[1], with_shape=True))
(DynamicCache(key_cache=#2[T1s3x4x4x8,T1s3x4x4x8], value_cache=#2[T1s3x4x4x8,T1s3x4x4x8]),T1s1x1x1x8)
Guess the dynamic shapes¶
The following tool can be used to guess the dynamic shapes
the way torch.export.export() expects them.
mi = ModelInputs(Model(), inputs)
ds = mi.guess_dynamic_shapes()
pprint.pprint(ds)
(([[{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)},
{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)}],
[{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)},
{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)}]],
{3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)}),
{})
And finally the export.
The export is simple if transformers>=4.50, otherwise,
transformers needs to be patched.
onnx_diagnostic.torch_export_patches.torch_export_patches()
registers functions to serialize DynamicCache. This one is modified to make
the shape inference implemented in torch happy.
with torch_export_patches(patch_transformers=True):
ep = torch.export.export(model, inputs[0], dynamic_shapes=ds[0], strict=False)
print(ep)
ExportedProgram:
class GraphModule(torch.nn.Module):
def forward(self, cache_key_cache_0: "f32[s13, 4, s10, s38]", cache_key_cache_1: "f32[s13, 4, s10, s38]", cache_value_cache_0: "f32[s13, 4, s10, s38]", cache_value_cache_1: "f32[s13, 4, s10, s38]", z: "f32[1, 1, 1, s38]"):
#
sym_size_int_6: "Sym(s38)" = torch.ops.aten.sym_size.int(cache_key_cache_0, 3)
sym_stride_int: "Sym(s38)" = torch.ops.aten.sym_stride.int(cache_value_cache_0, 2)
sym_size_int_12: "Sym(s38)" = torch.ops.aten.sym_size.int(z, 3)
# No stacktrace found for following nodes
sym_size_int: "Sym(s13)" = torch.ops.aten.sym_size.int(cache_key_cache_0, 0)
#
eq: "Sym(True)" = sym_stride_int == sym_size_int_6; sym_stride_int = sym_size_int_6 = None
_assert_scalar_default = torch.ops.aten._assert_scalar.default(eq, "Runtime assertion failed for expression Eq(s53, s92) on node 'eq'"); eq = _assert_scalar_default = None
# No stacktrace found for following nodes
empty: "f32[s13, 4, 0, s38]" = torch.ops.aten.empty.memory_format([sym_size_int, 4, 0, sym_size_int_12], dtype = torch.float32, device = device(type='cpu'), pin_memory = False)
empty_1: "f32[s13, 4, 0, s38]" = torch.ops.aten.empty.memory_format([sym_size_int, 4, 0, sym_size_int_12], dtype = torch.float32, device = device(type='cpu'), pin_memory = False)
cat: "f32[s13, 4, s10, s38]" = torch.ops.aten.cat.default([empty, cache_key_cache_0], -2); empty = cache_key_cache_0 = None
cat_1: "f32[s13, 4, s10, s38]" = torch.ops.aten.cat.default([empty_1, cache_value_cache_0], -2); empty_1 = cache_value_cache_0 = None
empty_2: "f32[s13, 4, 0, s38]" = torch.ops.aten.empty.memory_format([sym_size_int, 4, 0, sym_size_int_12], dtype = torch.float32, device = device(type='cpu'), pin_memory = False)
empty_3: "f32[s13, 4, 0, s38]" = torch.ops.aten.empty.memory_format([sym_size_int, 4, 0, sym_size_int_12], dtype = torch.float32, device = device(type='cpu'), pin_memory = False); sym_size_int = sym_size_int_12 = None
cat_2: "f32[s13, 4, s10, s38]" = torch.ops.aten.cat.default([empty_2, cache_key_cache_1], -2); empty_2 = cache_key_cache_1 = None
cat_3: "f32[s13, 4, s10, s38]" = torch.ops.aten.cat.default([empty_3, cache_value_cache_1], -2); empty_3 = cache_value_cache_1 = None
# File: ~/github/onnx-diagnostic/_doc/examples/plot_export_with_dynamic_cache.py:40 in forward, code: z
add: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(z, cat); z = cat = None
add_1: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(add, cat_2); add = cat_2 = None
add_2: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(add_1, cat_1); add_1 = cat_1 = None
add_3: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(add_2, cat_3); add_2 = cat_3 = None
return (add_3,)
Graph signature:
# inputs
cache_key_cache_0: USER_INPUT
cache_key_cache_1: USER_INPUT
cache_value_cache_0: USER_INPUT
cache_value_cache_1: USER_INPUT
z: USER_INPUT
# outputs
add_3: USER_OUTPUT
Range constraints: {s13: VR[2, int_oo], s10: VR[2, int_oo], s38: VR[2, int_oo]}
Use string instead of DYNAMIC¶
ONNX exporter considers strings instead of DYNAMIC or AUTO to give names to every dimension.
dss = mi.guess_dynamic_shapes(auto="dim")
pprint.pprint(dss)
(([[{0: 'dim_0I_0o_0l0', 2: 'dim_0I_0o_0l2', 3: 'dim_0I_0o_0l3'},
{0: 'dim_0I_0o_1l0', 2: 'dim_0I_0o_1l2', 3: 'dim_0I_0o_1l3'}],
[{0: 'dim_0I_1o_0l0', 2: 'dim_0I_1o_0l2', 3: 'dim_0I_1o_0l3'},
{0: 'dim_0I_1o_1l0', 2: 'dim_0I_1o_1l2', 3: 'dim_0I_1o_1l3'}]],
{3: 'dim_1I3'}),
{})
Do we need to guess?¶
Function onnx_diagnostic.helpers.string_type() is using
the serialization functions to print out the DynamicCache the was
torch.export.export() expects them.
print(string_type(cache, with_shape=True))
DynamicCache(key_cache=#2[T1s2x4x3x7,T1s2x4x3x7], value_cache=#2[T1s2x4x3x7,T1s2x4x3x7])
You can also use function
onnx_diagnostic.helpers.cache_helper.flatten_unflatten_for_dynamic_shapes()
to show a DynamicCache restructured the way torch.export.export() expects
it to be without the custom class.
print(string_type(flatten_unflatten_for_dynamic_shapes(cache), with_shape=True))
#2[#2[T1s2x4x3x7,T1s2x4x3x7],#2[T1s2x4x3x7,T1s2x4x3x7]]
This code works for any custom class if it was registered
with torch.utils._pytree.register_pytree_node().
doc.plot_legend("dynamic shapes\nfor DynamicCache", "torch.export.export", "tomato")
Total running time of the script: (0 minutes 5.635 seconds)
