Export with DynamicCache and guessed dynamic shapes¶
Every LLMs implemented in transformers use cache.
One of the most used is transformers.cache_utils.DynamicCache.
The cache size is dynamic to cope with the growing context.
The example shows a tool which determines the dynamic shapes
for torch.export.export() based on a set of valid inputs.
DynamicCache¶
torch.export.export() serializes caches and any custom class
if these serialization functions are provided with is the case for
transformers.cache_utils.DynamicCache and transformers>=4.50.
The dynamic shapes must be provided following the serialized form.
import pprint
import torch
from onnx_diagnostic import doc
from onnx_diagnostic.ext_test_case import has_transformers
from onnx_diagnostic.helpers import string_type
from onnx_diagnostic.helpers.cache_helper import (
flatten_unflatten_for_dynamic_shapes,
make_dynamic_cache,
)
from onnx_diagnostic.export import ModelInputs
from onnx_diagnostic.torch_export_patches import torch_export_patches
class Model(torch.nn.Module):
def forward(self, cache, z):
return (
z
+ cache.key_cache[0]
+ cache.key_cache[1]
+ cache.value_cache[0]
+ cache.value_cache[1]
)
model = Model()
n_layers = 2
bsize, nheads, slen, dim = 2, 4, 3, 7
cache = make_dynamic_cache(
[
(torch.randn(bsize, nheads, slen, dim), torch.randn(bsize, nheads, slen, dim))
for i in range(n_layers)
]
)
z = torch.randn((1, 1, 1, 7))
model(cache, z) # to check it works.
tensor([[[[-1.1534, -0.4810, -2.7559, 3.5524, -2.6642, -6.1048, 1.8736],
[-3.9018, 0.7266, -0.9381, 2.3329, -0.8829, -3.8779, 5.9116],
[-1.8228, 0.0299, -0.7934, 4.2816, -6.3535, -4.2360, 0.2349]],
[[-4.2640, -0.9247, -0.1411, -0.1737, -2.9008, 0.1997, -2.6438],
[ 0.0840, 0.3889, -1.0523, -2.6057, 1.6853, -2.1530, 0.4002],
[-1.9219, 3.2423, -1.8033, -0.0108, 2.5272, -3.9575, -0.7794]],
[[ 0.4002, 0.3289, -2.8407, -0.4206, -1.8948, -3.8877, 0.5374],
[-2.2765, -0.7927, -4.1071, -0.1069, 0.7096, -4.7109, -1.4282],
[-0.4841, -1.5750, -5.2166, 2.3293, 0.1353, -3.6288, 2.4231]],
[[ 1.7191, 4.5104, -3.7494, 1.9053, 0.3526, -2.1625, -2.1564],
[-0.8744, 0.0809, -1.1439, 0.9984, -1.3885, -1.2748, -0.3671],
[-0.1743, -2.0525, -1.0917, 0.8684, 0.4196, 0.3833, 1.2645]]],
[[[-0.3088, 0.2936, 0.0545, 2.4301, -2.2080, -1.8228, 1.0070],
[ 1.7969, 1.2497, -3.1076, 1.4958, -0.7197, -4.4798, 1.3573],
[-0.7751, 1.8067, -0.6388, -4.9977, 1.1114, -0.6417, 1.9996]],
[[ 0.3497, -0.9197, -5.6521, 1.2137, 1.2347, -2.8634, 1.7814],
[ 0.4986, -2.1289, -0.8862, 2.4905, -3.3386, 1.3207, 1.8182],
[-0.2019, -6.7506, -0.7204, 2.6980, -1.3016, -3.3119, 1.6042]],
[[-0.1474, -0.1328, -1.6456, 1.4732, 0.2217, -4.2840, 0.6970],
[ 2.9944, 3.0970, -0.5592, 2.8136, 0.2917, 0.7529, 0.5986],
[-0.7545, -0.6447, -2.5607, 2.9409, -0.1490, -0.8170, -3.2199]],
[[ 1.5678, -1.4138, -0.4724, -0.3759, 3.2607, -1.3677, 0.0093],
[ 0.5380, 0.7210, 0.5958, -0.3307, -3.4815, -0.7025, 0.2686],
[-1.3187, -0.6886, -2.0378, 3.1369, 1.6712, 0.9054, 0.0266]]]])
The cache looks like this:
print(string_type(cache, with_shape=True))
DynamicCache(key_cache=#2[T1s2x4x3x7,T1s2x4x3x7], value_cache=#2[T1s2x4x3x7,T1s2x4x3x7])
cache2 = make_dynamic_cache(
[
(
torch.randn(bsize + 1, nheads, slen + 1, dim + 1),
torch.randn(bsize + 1, nheads, slen + 1, dim + 1),
)
for i in range(n_layers)
]
)
inputs = [
(cache, z),
(cache2, torch.randn((1, 1, 1, 8))),
]
And the second set of inputs looks like:
print(string_type(inputs[1], with_shape=True))
(DynamicCache(key_cache=#2[T1s3x4x4x8,T1s3x4x4x8], value_cache=#2[T1s3x4x4x8,T1s3x4x4x8]),T1s1x1x1x8)
Guess the dynamic shapes¶
The following tool can be used to guess the dynamic shapes
the way torch.export.export() expects them.
mi = ModelInputs(Model(), inputs)
ds = mi.guess_dynamic_shapes()
pprint.pprint(ds)
(([[{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)},
{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)}],
[{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)},
{0: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
2: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True),
3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)}]],
{3: _DimHint(type=<_DimHintType.DYNAMIC: 3>,
min=None,
max=None,
_factory=True)}),
{})
And finally the export.
The export is simple if transformers>=4.50, otherwise,
transformers needs to be patched.
onnx_diagnostic.torch_export_patches.torch_export_patches()
registers functions to serialize DynamicCache. This one is modified to make
the shape inference implemented in torch happy.
if has_transformers("4.50"):
ep = torch.export.export(model, inputs[0], dynamic_shapes=ds[0], strict=False)
else:
with torch_export_patches(patch_transformers=True) as modificator:
ep = torch.export.export(
model, modificator(inputs[0]), dynamic_shapes=ds[0], strict=False
)
print(ep)
ExportedProgram:
class GraphModule(torch.nn.Module):
def forward(self, cache_key_cache_0: "f32[s13, 4, s10, s38]", cache_key_cache_1: "f32[s13, 4, s10, s38]", cache_value_cache_0: "f32[s13, 4, s10, s38]", cache_value_cache_1: "f32[s13, 4, s10, s38]", z: "f32[1, 1, 1, s38]"):
#
sym_size_int: "Sym(s13)" = torch.ops.aten.sym_size.int(cache_key_cache_0, 0)
sym_size_int_1: "Sym(s10)" = torch.ops.aten.sym_size.int(cache_key_cache_0, 2)
sym_size_int_2: "Sym(s38)" = torch.ops.aten.sym_size.int(cache_key_cache_0, 3)
sym_size_int_3: "Sym(s13)" = torch.ops.aten.sym_size.int(cache_key_cache_1, 0)
sym_size_int_4: "Sym(s10)" = torch.ops.aten.sym_size.int(cache_key_cache_1, 2)
sym_size_int_5: "Sym(s38)" = torch.ops.aten.sym_size.int(cache_key_cache_1, 3)
sym_size_int_6: "Sym(s13)" = torch.ops.aten.sym_size.int(cache_value_cache_0, 0)
sym_size_int_7: "Sym(s10)" = torch.ops.aten.sym_size.int(cache_value_cache_0, 2)
sym_size_int_8: "Sym(s38)" = torch.ops.aten.sym_size.int(cache_value_cache_0, 3)
sym_size_int_9: "Sym(s13)" = torch.ops.aten.sym_size.int(cache_value_cache_1, 0)
sym_size_int_10: "Sym(s10)" = torch.ops.aten.sym_size.int(cache_value_cache_1, 2)
sym_size_int_11: "Sym(s38)" = torch.ops.aten.sym_size.int(cache_value_cache_1, 3)
sym_size_int_12: "Sym(s38)" = torch.ops.aten.sym_size.int(z, 3)
# File: ~/github/onnx-diagnostic/_doc/examples/plot_export_with_dynamic_cache.py:39 in forward, code: z
add: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(z, cache_key_cache_0); z = cache_key_cache_0 = None
#
eq: "Sym(True)" = sym_size_int_12 == sym_size_int_2; sym_size_int_2 = None
_assert_scalar_default = torch.ops.aten._assert_scalar.default(eq, "Runtime assertion failed for expression Eq(s38, s92) on node 'eq'"); eq = _assert_scalar_default = None
eq_1: "Sym(True)" = sym_size_int_12 == sym_size_int_5; sym_size_int_5 = None
_assert_scalar_default_1 = torch.ops.aten._assert_scalar.default(eq_1, "Runtime assertion failed for expression Eq(s38, s57) on node 'eq_1'"); eq_1 = _assert_scalar_default_1 = None
eq_2: "Sym(True)" = sym_size_int_1 == sym_size_int_4; sym_size_int_4 = None
_assert_scalar_default_2 = torch.ops.aten._assert_scalar.default(eq_2, "Runtime assertion failed for expression Eq(s10, s29) on node 'eq_2'"); eq_2 = _assert_scalar_default_2 = None
eq_3: "Sym(True)" = sym_size_int == sym_size_int_3; sym_size_int_3 = None
_assert_scalar_default_3 = torch.ops.aten._assert_scalar.default(eq_3, "Runtime assertion failed for expression Eq(s33, s93) on node 'eq_3'"); eq_3 = _assert_scalar_default_3 = None
eq_4: "Sym(True)" = sym_size_int_12 == sym_size_int_8; sym_size_int_8 = None
_assert_scalar_default_4 = torch.ops.aten._assert_scalar.default(eq_4, "Runtime assertion failed for expression Eq(s38, s53) on node 'eq_4'"); eq_4 = _assert_scalar_default_4 = None
eq_5: "Sym(True)" = sym_size_int_1 == sym_size_int_7; sym_size_int_7 = None
_assert_scalar_default_5 = torch.ops.aten._assert_scalar.default(eq_5, "Runtime assertion failed for expression Eq(s10, s19) on node 'eq_5'"); eq_5 = _assert_scalar_default_5 = None
eq_6: "Sym(True)" = sym_size_int == sym_size_int_6; sym_size_int = None
_assert_scalar_default_6 = torch.ops.aten._assert_scalar.default(eq_6, "Runtime assertion failed for expression Eq(s33, s13) on node 'eq_6'"); eq_6 = _assert_scalar_default_6 = None
eq_7: "Sym(True)" = sym_size_int_12 == sym_size_int_11; sym_size_int_12 = sym_size_int_11 = None
_assert_scalar_default_7 = torch.ops.aten._assert_scalar.default(eq_7, "Runtime assertion failed for expression Eq(s38, s97) on node 'eq_7'"); eq_7 = _assert_scalar_default_7 = None
eq_8: "Sym(True)" = sym_size_int_1 == sym_size_int_10; sym_size_int_1 = sym_size_int_10 = None
_assert_scalar_default_8 = torch.ops.aten._assert_scalar.default(eq_8, "Runtime assertion failed for expression Eq(s10, s42) on node 'eq_8'"); eq_8 = _assert_scalar_default_8 = None
eq_9: "Sym(True)" = sym_size_int_6 == sym_size_int_9; sym_size_int_6 = sym_size_int_9 = None
_assert_scalar_default_9 = torch.ops.aten._assert_scalar.default(eq_9, "Runtime assertion failed for expression Eq(s13, s25) on node 'eq_9'"); eq_9 = _assert_scalar_default_9 = None
# File: ~/github/onnx-diagnostic/_doc/examples/plot_export_with_dynamic_cache.py:39 in forward, code: z
add_1: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(add, cache_key_cache_1); add = cache_key_cache_1 = None
add_2: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(add_1, cache_value_cache_0); add_1 = cache_value_cache_0 = None
add_3: "f32[s13, 4, s10, s38]" = torch.ops.aten.add.Tensor(add_2, cache_value_cache_1); add_2 = cache_value_cache_1 = None
return (add_3,)
Graph signature:
# inputs
cache_key_cache_0: USER_INPUT
cache_key_cache_1: USER_INPUT
cache_value_cache_0: USER_INPUT
cache_value_cache_1: USER_INPUT
z: USER_INPUT
# outputs
add_3: USER_OUTPUT
Range constraints: {s13: VR[2, int_oo], s10: VR[2, int_oo], s38: VR[2, int_oo]}
Use string instead of DYNAMIC¶
ONNX exporter considers strings instead of DYNAMIC or AUTO to give names to every dimension.
dss = mi.guess_dynamic_shapes(auto="dim")
pprint.pprint(dss)
(([[{0: 'dim_0I_0o_0l0', 2: 'dim_0I_0o_0l2', 3: 'dim_0I_0o_0l3'},
{0: 'dim_0I_0o_1l0', 2: 'dim_0I_0o_1l2', 3: 'dim_0I_0o_1l3'}],
[{0: 'dim_0I_1o_0l0', 2: 'dim_0I_1o_0l2', 3: 'dim_0I_1o_0l3'},
{0: 'dim_0I_1o_1l0', 2: 'dim_0I_1o_1l2', 3: 'dim_0I_1o_1l3'}]],
{3: 'dim_1I3'}),
{})
Do we need to guess?¶
Function onnx_diagnostic.helpers.string_type() is using
the serialization functions to print out the DynamicCache the was
torch.export.export() expects them.
print(string_type(cache, with_shape=True))
DynamicCache(key_cache=#2[T1s2x4x3x7,T1s2x4x3x7], value_cache=#2[T1s2x4x3x7,T1s2x4x3x7])
You can also use function
onnx_diagnostic.helpers.cache_helper.flatten_unflatten_for_dynamic_shapes()
to show a DynamicCache restructured the way torch.export.export() expects
it to be without the custom class.
print(string_type(flatten_unflatten_for_dynamic_shapes(cache), with_shape=True))
#2[#2[T1s2x4x3x7,T1s2x4x3x7],#2[T1s2x4x3x7,T1s2x4x3x7]]
This code works for any custom class if it was registered
with torch.utils._pytree.register_pytree_node().
doc.plot_legend("dynamic shapes\nfor DynamicCache", "torch.export.export", "tomato")
Total running time of the script: (0 minutes 0.362 seconds)
